DAA-1  Max 500W

1ch class-D car amplifier

● 2 Ohms Rms Output Power: 1×500W

● 4 Ohms Rms Output Power: 1×350W

● Fuse Rating: 30A*2

● Dimensions: W136*L198*H44(mm)

DAA-2  Max 240W

2ch class-D car amplifier

● 2 Ohms Rms Output Power: 2×120W

● 4 Ohms Rms Output Power: 2×80W

● 4 Ohms Bridge Output Power: 1×240W

● Fuse Rating: 25A*1

● Dimensions: W101.5*L147*H44(mm)

DAA-4  Max 300W

4ch class-D car amplifier

● 2 Ohms Rms Output Power: 4×80W

● 4 Ohms Rms Output Power: 4×50W

● 4 Ohms Bridge Output Power: 2×150W

● Fuse Rating: 30A*1

● Dimensions: W101.5*L147*H44(mm)

DAA-6  Max 450W

6ch class-D car amplifier

● 2 Ohms Rms Output Power: 6×80W

● 4 Ohms Rms Output Power: 6×50W

● 4 Ohms Bridge Output Power: 3×150W

● Fuse Rating: 40A*1

● Dimensions: W117.5*L170*H44(mm)

DAA-8  Max 600W

8ch class-D car amplifier

● 2 Ohms Rms Output Power: 8×80W

● 4 Ohms Rms Output Power: 8×50W

● 4 Ohms Bridge Output Power: 4×150W

● Fuse Rating: 30A*2

● Dimensions: W133.5*L198*H44(mm)

Specifications

● Distortion (THD): 0.1%

● Low Pass Crossover: 50Hz to 5000Hz

● High Pass Crossover: 40Hz to 4000Hz

● Frequency Response: 10Hz to 22KHz

● Signal to Noise Ratio: (Reference 1W

   into 4 Ohms) >80dB

● Stereo Separation:  >50dB

● Input Sensitivity: 0.1V to 6V
